Specifications
Please note - specifications subject to change without prior notice.
| FRAME | Aluminum, Smooth Welding, 9x135mm QR, 26" |
| FORK | SR Suntour XCR Air w/ Light Tune, 100mm , 9X100 QR |
| HEADSET | External Cup Ball Bearing, 1-1/8" EC 34 |
| GRIPS | Norco Youth, 115mm Length |
| HANDLE BAR | 6061 Alloy DB 1.6mm , 720mm, 20mm rise |
| STEM | Alloy 45mm Length, 31.8mm Clamp |
| SEAT POST | Norco Alloy 27.2mm, 250mm length |
| SADDLE | Norco Jr XC, Steel Rail |
| FRONT BRAKE | Tektro HD-M286, Resin Pads |
| FRONT BRAKE ROTOR | Tektro. 160mm rotor, 6-bolt |
| REAR BRAKE | Tektro HD-M286, Resin Pads |
| REAR BRAKE ROTOR | Tektro. 160mm rotor, 6-bolt |
| BRAKE LEVERS | Tektro HD-M286, Hydraulic 2-Finger Jr. Levers |
| SHIFTER REAR | Shimano Cues SL-U4000, 9sp |
| REAR DERAILLEUR | Shimano Cues RD-U4000, 9sp, GS |
| CASSETTE | Shimano Cues CS-LG300-9, 11-46T, 9sp |
| CHAIN | KMC Z9 |
| CRANKSET | Samox Alloy 3pc, 152mm, 28T Narrow Wide |
| BOTTOM BRACKET | Sealed bearing, ST 68mm |
| FRONT HUB | Formula DC-1420 , 9x100mm QR, 28h, 6-bolt |
| REAR HUB | Formula DC-1425,10x135mm QR, HG, 32H, 6-bolt |
| SPOKES/NIPPLES | Stainless Steel w/Brass Nipples |
| RIMS | Aluminum DW, 28h, 26" MTB |
| FRONT TIRE | CY H-5183 MTB Trail tire, 26x2.25”, Wire |
| REAR TIRE | CY H-5183 MTB Trail tire, 26x2.25”, Wire |
